GI Electric Boxes

Electrical Boxes are an integral part of any electrical layout while construction. They remain hidden from sight but their role in electrification of home or office is very important.
Modular Boxes
Modular Boxes, also known as Switch Boxes are used for mounting switchboards, and they also act like junction points.

Nominal Sizes (inch) : 3x3 4x3 5x3 8x3 9x3 5x5 8x6 8x8
No. of Modules : 1&2 3 4 6 8 8 12 18
Nominal Thickness (nmm): 0.9, 1.2
Material : Galvanized Iron (GI)
Fan Boxes
Fan Boxes are metal boxes consisting of on iron rod which forms a hook lo install ceiling fans.

Box Height (inch) : 2" 2.5" 3" 3"
Rod OD (mm) : 10 12 12 12
Rod Length (inch) : 10 120 16 16
Series : AX (Lock Type) LX (Draw Type)
Material : Galvanized Iron (GI) Cold Rolled Coil (CRC)


Concealed Boxes
Concealed Boxes are another type of metal boxes, which acts as electrical junction points in slabs, and are primarily used to install concealed lights in ceilings.

Box Height : 2.5
Series AX (Lock Type), LX (Draw Type)
Material Galvanized Iron (Gl). Cold Rolled Coil (CRC)
